Y35 is a 7‑channel NTC input module belonging to the Y series I/O modules for IOy and ARMxy series products. It is designed for resistance measurement of 10K3A1 type NTC thermistors. Temperature conversion from resistance to degrees Celsius is performed by the customer’s software application, offering maximum flexibility for various thermistor curves and calibration requirements.
Y35 is a 7‑channel NTC input module belonging to the Y series I/O modules for IOy and ARMxy series products. It is designed for resistance measurement of 10K3A1 type NTC thermistors, with a measurement range of 667,828 Ω to 184.8 Ω. The module features 16‑bit ADC resolution and outputs raw resistance values (in Ω) via the fieldbus. Temperature conversion from resistance to degrees Celsius is performed by the customer’s software application, offering maximum flexibility for various thermistor curves and calibration requirements.
| No. | Model | Signal Type |
|---|---|---|
| 1 |
Y01 |
4xDI+4xDO(NPN) |
| 2 |
Y02 |
4xDI+4xDO(PNP) |
| 3 |
Y11 |
8xDI(NPN) |
| 4 |
Y12 |
8xDI(PNP) |
| 5 |
Y13 |
8xDI(Dry Contact) |
| 6 |
Y21 |
8xDO(PNP) |
| 7 |
Y22 |
8xDO(NPN) |
| 8 |
Y24 |
4xDO(Relay) |
| 9 |
Y31 |
4xAI, Single-ended, 0~20mA/4~20mA |
| 10 |
Y33 |
4xAI, Single-ended, 0~5V/0~10V |
| 11 |
Y34 |
4xAI, Differential, 0~5V/0~10V |
| 12 |
Y35 |
7x NTC Input |
| 13 |
Y36 |
4xAI, Differential, ±5V/±10V |
| 14 |
Y41 |
4xAO, 0~20mA/4~20mA |
| 15 |
Y42 |
1xAO, 0~5V/0~10V |
| 16 |
Y43 |
4xAO, 0~5V/0~10V |
| 17 |
Y46 |
4xAO, ±5V/±10V |
| 18 |
Y51 |
2xRTD, 3-Wire PT100 |
| 19 |
Y52 |
2xRTD, 3-Wire PT1000 |
| 20 |
Y53 |
2xRTD, 4-Wire PT100 |
| 21 |
Y54 |
2xRTD, 4-Wire PT1000 |
| 22 |
Y56 |
Resistance Measurement |
|
23 |
Y57 |
Voltage Measurement |
|
24 |
Y58 |
4xTC |
|
25 |
Y63 |
4xRS485 or RS232 |
|
26 |
Y95 |
4xPWM Output(NPN) + 4xPulse Counter Input |
|
27 |
Y96 |
4xPWM Output(PNP) + 4xPulse Counter Input |
